Duplo DC445 Creaser

The Duplo DC-445 DuCreaser is specifically designed to meet the needs of the short-run digital colour print market, providing a creasing solution for the problem of toner/ink cracking which results when digitally printed work is folded. Offering high speeds, full automation, simple programming and up to 30 memories, it provides a highly productive solution for the creative finishing of a range of digitally produced promotional and direct mail items including flyers, leaflets, brochures, CD covers and greetings cards. The DuCreaser is also equally suited to finishing offset printed card or laminated stocks. The perfect solution whatever your print engine The DuCreaser has been designed to economically match environments with 30-80ppm digital printers, however at operating speeds of up to 50 sheets per minute it is equally capable of handling rated output from 110ppm digital printers as well.

Prevent toner cracking and unattractive fold lines with Duplo’s DC-445 Creaser. A simple and affordable finishing solution no digital printer should do without, the DC-445 creases a wide range of applications at up to 50 sheets per minute. Creasing digitally-printed output prior to folding ensures a clean, professional finish and makes it easier for folding devices to bend with accuracy. The DC-445 applies up to 15 creases in a single pass with great precision and is perfect for creating unique accordion applications and other color documents that require a fold right along the color break. Fully automatic and easy to use, the DC-445 is ideal for finishing short-run offset and digital applications, including greeting cards, postcards, brochures, book covers, and more!

Optional features are also available to maximize its functionality. An air-knife provides additional air to improve feed consistency and reduce static problems while double-feed detectors stop the machine when two or more sheets are fed, thus preventing mis-feeds and paper jams. Additionally, slitting and perforating modules can be added to eliminate white borders and create perforated pieces. Up to three slitting and perforating modules can be installed for increased versatility.



Play Product Video

Category:

Description

Technical Data

  • Feeder Capacity – 100mm (Exit try 110mm)
  • Feeder type: top feed belt
  • Speed: A4 50 sheets per minute, A3 39 sheets PM
  • Paper sizes Min 140mm x 150mm
  • Paper sizes Max: 320mm x 650mm
  • Paper weights: 110gsm to 350gsm
  • Max creases: 15 per sheet
  • Crease depths: 3 – min, med, max
  • Programs: 30
  • Options: perfs, slitters, air knife
  • Power: 230v AC 50HZ
  • Dimensions: (L x W x D) 1262 x 618 x 1090mm
  • Weight: 114KG

Features

  • Up to 15 Creases per sheet
  • 30 Job programmable set up and storage
  • Up to 50 A4 sheets per minute
  • 110-350gsm nominal paper range
  • 110mm Feed Pile Height for unattended operation
  • Suction feed to eliminate marking (No compressors so also quiet)
  • 0.1mm increments and +/- 0.3mm accuracy
  • Optional perforating and slitting modules
  • Step by step setup panel

Typical Uses

  • Greeting Cards
  • Two and Three way folded leaflets
  • Tickets, Brochures
  • Book Covers
  • CD/DVD Covers
  • Menu Cards
  • Post Cards
  • Flyers & Mailers
